Use:
The most versatile cooling and heating tool a winery can own
Pump must or wine throught the machine | Heats or cools inline
The only practical solution for cooling or heating crushed grapes
2" ID stainless steel tube-in-tube heat exchanger allows crushed grapes to pass through
Use your choice of pumps to move product through SR chiller/heater
Made in Germany | Used for over 40 years in French and German wineries
Features:
Plenty of Power | 11.7 Tons (140,400btu) of Cooling power
Wide Temperature Range | 28F or up to 113F
Moves Where You Need It | Rolls on four locking casters
Control Temperatures with Ease | Digital Thermostat
Top Class Components
The most versatile cooling and heating tool a winery can own. Whether you want to cool crushed grapes to cold soak temperatures, heat a sluggish ferment, heat a tank for ML without having a dedicated hot water loop, or cold stabilize a tank quickly, the SR is an extremely useful machine. It often eliminates the need for a separate heating loop in your winery. It is loved for quickly doing cold stabilization on one tank at a time. It is more effective at cooling crushed grapes than trying to cool in a tank. Because it is a closed system it can be used with sparkling wine or cider without losing carbonation.
Most wineries who use an SR for cooling/heating specific tanks or vats also have a dedicated main chiller connected to their permanent cooling loop. However the SR can also act as the back up chiller in case your main chiller goes down. You can use the SR to chill a tank, such as a large HDPE tank. Connect that tank to your glycol loop and if your main chiller goes down you already have a backup plan in place.
Made in Germany, thousands of Kreyer SR chillers have been in use for over 40 years in France and Germany.
The SR is not like a regular glycol chiller where a cooled bath is pumped into the tank jackets. The SR features a large, tubular heat-exchanger that is completely insulated. Your product is pumped through the inner tube while heat or cold travels the opposite direction through the outer tube. The top half of the SR houses the compressor for cooling while heating is performed in the Heat-Pump operation mode. The SR is uniquely designed unit for changing the temperature inline of crushed grapes, wine, sparkling wine, water, cider, fruit juice and distillates.
By setting the temperature, you can rely on the SR to maintain tank temperature for as long as needed, in either heating or cooling mode.
The case of the unit as well as all parts that come in contact with the treated medium are made of stainless steel. The ventilation grills are lacquered in black. Due to its four wheels, this SR unit is easy to maneuver. This allows the user to cool or to heat single tanks or other containers, as required. For example: starting a stopped fermentation by heating the tank content. Your choice of external pump is controlled by the SR’s control panel.
The cooling units of the SR series are available in seven different sizes. This is 11.7 Ton model. Smaller and larger machines are available for quote.
Applications:
Direct cooling or heating of must at the beginning of fermentation
Tartaric stabilization of wines
Warming up wine from storage to bottling temperature
Biological reduction of acids
Regulation of fermentation temperature
Cool storage of wine until bottling
Suitable for sparkling wine and carbonated beverages (closed loop with no carbonation loss)
Cooling of liquids with particles such as unfiltered juice
Air cooling of the cellar in combination with additional equipment (thermo-fans and accessories)
Check out these features:
Cools or Heats
11.7 Tons (140,400btu) of cooling power
Can maintain temps from 23F to 113F.
230V 60Hz 3 phase supply voltage drawing 40 amps
Mobile unit with 4 casters, two locking
Sheet metal housing, electrolytic galvanized high surface quality, powder-coated and abrasion-resistant casing
Control an external cellar pump from the SR's control panel
Evaporator coil made of stainless steel
Automatic control of the wine pump according to set temperature
Digital Thermostat
Lifting/Crane Hooks for transport
Panels remove for easy access
All units pass multiple tests prior to shipment
German Engineering
Controller display shows temperature accuracy up to 0.1 degree Celsius.
41.3"L x 41.3"W x 84.6"T
Empty Weight: 992 lbs
Unit has 2" tri-clamp inlet / outlet
6 Month Electrical Warranty
1 Year Mechanical Warranty
CE Certified
Please Note: This unit REQUIRES 230 v Three Phase power and will not function on anything else. Please confirm that you have the proper power for this unit before purchasing, and plan to have a qualified electrician wire the necessary plug to the cord.
