KegLand is a high quality homebrewing equipment brand based out of Australia. We offer a wide variety of their products, from BrewZilla all-in-one system and DigiBoil eletric kettles, to pumps and grain mills. KegLand beer products are an incredible value, as they combine quality craftsmanship with low prices!
The Gen 2 DigiBoil features two distinct updates that are not currently pictured in the primary images. The stainless steel lid has been upgraded to a glass lid, allowing you to observe and monitor boil activity. The rubber feet have been replaced with a plastic base that provides improved stability and slightly raises the unit for better ground clearance. Updated images coming soon. The most affordable all-in-one automated all-grain brewing system! Mash grains and boil wort in a single vessel External pump kit for recirculating mash will improve efficiency, consistency, and clarity DigiBoil electric kettle automatically maintains mash temperatures with the digital controller Dual heating elements combine for 2400W of power The DigiMash system represents the best value in electric all-grain brewing you'll find. With a 9-gallon DigiBoil electric kettle and the DigiMash stainless steel mashing accessory pack included, this is by far the most affordable way to get into electric all-grain brewing. It may not have all the bells and whistles of the BrewZilla, but it does have everything you need to mash and boil all in one unit. With the Recirculation Pump Kit, you can recirculate sweet wort during the mash to improve starch conversion, maintain a consistent temperature throughout the mash, and improve the clarity. The pump can also be used to move water around your brewery if you use a secondary vessel to hold sparge water, or to transfer the wort from your kettle to your fermenter. With the optional Whirlpool Arm, you can also swap out the Recirculation Arm and use your pump kit to whirlpool after the boil. If you're deciding between the DigiMash and the BrewZilla, there are a couple of key differences worth noting. One of our favorite features of the BrewZilla is the programmable mash steps and delayed start, which the DigiMash does not have. You can still step mash by simply raising the temperature manually on the controller, but the automatic steps are a convenient feature if you want to set it and forget it. One advantage that this setup has over the BrewZilla is that the pump is external. This makes cleaning and fixing pump issues much easier, as you can quickly take apart the pump head to clean and clear out residual gunk at the end of each brew day. This model comes with the 35L DigiBoil, which has two built-in heating elements that run off a 220V plug. One element is 1900w and the other is 500w for a combined 2400 watts! The elements can be individually controlled, allowing you to use a single element to gently hold temperatures, or engage both elements to quickly go from mash temp to boiling. Temperatures are set and automatically maintained through the digital control panel. Simply set your desired temperature and flip on the heating element(s). DigiBoil Features: 304 stainless steel construction 9-gallon total capacity Digital temperature control 220V / 15A power NEMA 6-30R plug (5 ft. cord) Dual heating element control (1900w and 500w) Heating elements are concealed for easy cleaning 304 stainless steel 1/2" ball valve with 13mm barb (approx. 1/2") Stamped-in volume markers (gallons & liters) Stainless lid Temperature reads in °F or °C With elements turned off, hold both +/- buttons to switch between °F or °C Recommended max. grain bill - 18 lbs Recommended min. grain bill - 8 lbs External Dimensions: 29" H x 15" W (including handles) Internal Dimensions: 19.5" H x 11.75" W DigiMash Stainless Steel Accessory Pack Includes: False bottom Malt pipe Wire support Malt pipe handle Malt pipe bottom screen Recirculation Pump Kit Includes: High temp magnetic drive pump Recirculation arm with male camlock Female camlock with barb fitting 1/2" FPT x 1/2" barb fitting 1/2" MPT x 5/8" barb fitting 1/2" ball valve 5 ft. length of silicone tubing 4 x hose clamps Plumber's tape
Flanged tri-clamp gaskets extend over the ferrule, holding them securely in place for easy, frustration-free connections
EPDM gaskets are more resistant to acids and caustic chemicals, and don't show signs of wear as quickly as silicone
For 1.5" tri-clamp connections
A flanged tri-clamp gasket differs from a standard gasket or seal because one half of the flanged gasket extends over the edge of the T.C. ferrule, which holds it more securely in place. This makes the gaskets extremely easy to work with while clamping down connections, and helps you avoid the frustration of fumbling a freshly sanitized gasket onto the floor at the worst possible time.
Available in both EPDM and Silicone.
EPDM gaskets have a more narrow temperature range than silicone gaskets, but they are more resistant to acids and caustic chemicals.
For 1.5" tri-clamp fittings
Made from EPDM
Temperature rated from -30°F to 300°F
KegLand Part Number: KL45230
Example Image: Updated images coming soon. See the video below to check out the flanged gaskets in action.
This optional accessory for the Cannular Filler provides real-time temperature readings displayed directly on the unit during filling runs, helping prevent foaming issues caused by warm beverages
Temperature data is automatically logged to the RAPT cloud, providing valuable insights into your filling process and enabling consistent quality
Simple installation by opening the unit's case and plugging the probe into filler's circuit board
The Cannular Can and Bottle Filler offers an optional Instant Read Temperature Probe accessory. A common issue with rapid can and bottle filling is foaming, often caused by insufficiently chilled beverages. With Temperature Probe installed, you can monitor the temperature of your beverages throughout the filling run.
The Cannular Can and Bottle Filler's circuit board includes a dedicated plug for the temperature probe. To install the probe, open the casing and remove the grommet on top of the machine. Insert the probe through the grommet hole from the inside out, ensuring the cable and plug remain within the casing.
Once installed, the probe measures the beverage temperature during filling and displays it on the unit. This data is also transmitted to the RAPT cloud, where it is recorded with other filling run statistics.
KegLand Part Number: KL38171
RAPT Controller extension cable for the BrewZilla 35L, 65L and 100L Generation 4 models. Mount your screen up higher in your brew space and get a clear view on brew day.
Compatible with 110V / 220V models
4.9 ft. Cable Length (1.5 m)
Suitable only for Gen 4 BrewZillas
KegLand Part Number: KL32681
If you are an experienced single vessel brewer and don't use the overflow pipe. This malt pipe screen is the perfect upgrade for just that! The Gen 4 BrewZilla nixed the overflow pipe, so this is a direct replacement part for that unit. But this screen can also be used with the Gen 3 BrewZilla if you don't use the overflow pipe.
KegLand Part Number: KL14243
Includes every replacement seal for the NukaTap Flow Control faucet, ensuring you're prepared for any maintenance needs
This kit contains all the seals needed to upgrade a Gen 1 NukaTap Flow Control faucet to the Gen 2 mechanism, improving performance and longevity
Provides a full set of seals to quickly fix leaks, replace lost seals, or maintain taps used in demanding settings
This complete kit provides all the replacement seals you need for the Gen 2 NukaTap Flow Control faucet. If you have the Gen 1 Flow Control model, you can use the improved flow control mechanism in this kit to effectively upgrade your faucet to the Gen 2 Flow Control model.
Most of the seals in this kit are durable and won't require frequent replacement. However, if you experience a leak, accidentally lose a seal, or use the tap in a demanding commercial environment, this kit has you covered.
When replacing seals, we recommend applying a food-grade lubricant to ensure a long-lasting and secure fit. As you take the tap apart, it can also be helpful to take a picture or make a note of where each seal is located to make reassembly easier.
Includes:
The Nuke!
Bonnet Washer
2 x Black POK Cup Seal Washers
Nozzle Washer
Flow Control Arm Seals
Flow Control Arm Thread Seals
Gen 2 Flow Control Mechanism
KegLand Part Number: KL44950
The Ultimate Grain to Glass Combo Pack! Get the Gen 4 BrewZilla & FermZilla Easy-Grip Tri-Conical with all the best accessories at an unbeatable price!
Brew extract or all grain batches on the BrewZilla; ferment, carbonate, and serve from the FermZilla. Everything you need from Grain to Glass!
Comes with all of the most highly recommended accessories for the BrewZilla, including the Neoprene Jacket to speed up heating times, Hop Spider to keep vegetal matter out of your wort, and Chilling Connection kit so you're ready to use the Immersion Chiller out of the box
Includes some of our favorite accessories for the FermZilla, such as the Pressure Kit with Floating Dip Tube so you're always racking the clearest beer and the Duotight BlowTie 2 for pressure fermentations and flow control keg transfers
Over $100 savings when purchasing this kit bundle compared to buying everything piece-by-piece!
Also available in 110V (AG580)
You can search high and low, but you won't find a better deal than the BrewZilla Ultimate Grain to Glass Combo Pack!
Combo Pack Includes:
BrewZilla Brewing System | Gen 4.1 | 9.25G | 220V
Neoprene Jacket
Hop Spider
Wort Chiller Connection Kit
FermZilla Tri-Conical Fermenter | Gen 3.2 | 7.1G
Plastic Pressure Kit w/ Floating Dip Tube
Duotight BlowTie 2 Spunding Valve
Insulating Jacket
Gen 4 BrewZilla All-in-One Brewing System
WiFi / Bluetooth enabled RAPT Controller tracks your brewday and automatically uploads detailed information to the RAPT portal
The top mounted RAPT Controller can be tilted upward for easy viewing, or detached from the unit to mount it on the wall or placed on your bench
Mirror polished dome shaped bottom with center drain — get every last bit of wort into your fermenter while the perforated bottom screen filters out 95% of hot break and hop matter
Make larger batches or higher gravity beers! BrewZilla offers the largest malt pipe capacity for units in its size range, and the Gen 4 unit has a 30% larger malt pipe compared to the previous generation
Perforated bottom on the newly designed malt pipe allows for improved mash recirculation flow without sacrificing efficiency
Element power percentage can be adjusted via the RAPT Controller. Go full power to heat up quickly, or dial it down so you don’t overshoot your strike water temp
The built-in pump is plumbed to both the recirculation and arm and the bottom ball valve. Recirculate wort during your mash, then close the recirculation valve and pump wort to your fermenter via the bottom valve
Pair with the RAPT-enabled Bluetooth Thermometer, allowing your BrewZilla to calculate a core mash temperature reading and more accurately control temperatures and mash steps
More RAPT-enabled accessories are coming, and future firmware updates can be downloaded to the RAPT Controller itself over the internet
WiFi/Bluetooth Enabled RAPT Controller
The RAPT Controller is mounted to the top of the boiler body, allowing for easy operation when you have the unit set on the ground. The controller can be tilted upwards to give you an even better view, or it can be removed from the BrewZilla entirely if you’d prefer to mount the controller on your wall or lay it down on a workbench. From the controller, you’ll orchestrate your entire brew day. Program mash steps, dial in element power, and operate the integrated pump all from one screen.
But the RAPT Controller is much more than a beautiful, full-color display switch board. Once synced to the RAPT Portal, you’ll be able to track, record and monitor your brews online. No need for handwriting notes or punching brew day details into your phone – all of the data from your brew is automatically logged to your portal profile. This information doesn’t just include your mash profile; it also captures detailed information about your element power and pump activity, opening the door for very precise repeatability.
And the RAPT Portal isn’t just a digital archive for your brew days. With your BrewZilla powered on, you can control your brewery from virtually anywhere using your phone’s web browser. Not sure when you’ll be home from work or your kid’s ball game going into extra innings? No problem! Before you head out, simply log into the RAPT Portal from your phone and tell the BrewZilla to start heating your strike water. Along with remote control, the portal enables you to program alarms and push notifications for all of your boil additions. We’ve all been caught up with a side task and failed to throw in that yeast nutrient or clarifying agent at the end of the boil, but the BrewZilla has the back of even the most forgetful brewer!
But wait, there’s more! In addition to WiFi connectivity, the RAPT Controller is also a Bluetooth gateway device. KegLand is currently developing various Bluetooth devices such as the Bluetooth Beacon Thermometer and other sensors which will be compatible with your brewery upon release. The RAPT Controller is able to receive information from Bluetooth Low Energy (BLE) devices, adjusting its processes based on this new stream of information while simultaneously logging it to your RAPT Portal. With the Bluetooth Beacon Thermometer, for example, you’ll be able to feed temperature readings from the top of your mash bed to the controller. The controller will then compare this reading with the main temp probe reading at the base of the kettle and adjust element cycling based on these combined readings.
Finally, the RAPT Controller WiFi connectivity allows you to update the controller’s firmware with a single click. Take advantage of new features and accessories as soon as they become available by simply keeping your BrewZilla connected to your local WiFi network. And again, the WiFi is already built-in! No need to come back for an expensive add-on accessory down the road.
High Capacity Malt Pipe
With an approximately 23.5 lb capacity, the BrewZilla can mash nearly 50% more grain than similar sized models of the Anvil Foundry and Grainfather G30. If you want to fill your fermenter with more than a 5-gallon batch worth of wort, or brew the highest gravity beer recipes, the BrewZilla is the brewhouse for the job. And the included malt pipe is just the beginning. If you want to expand your brewery’s grain capacity even further, KegLand makes Boiler Extension Kits and Extended Malt Pipes for that very purpose. The malt pipe features a perforated section at the bottom which improves mash recirculation flow without sacrificing efficiency.
Concave Base with Center Draining
Leave no wort behind! The concave base with center drain means you’ll be able to extract every last drop of wort to your fermenter. If you’ve brewed in a traditional flat bottom kettle, this center drain may be a bit perplexing at first. Many brewers are used to whirlpooling after the boil to pull hop matter into the center of the kettle, then transfer out using a pick-up tube that pulls from the kettle wall in order to avoid sucking up the solids. But fear not! One of the key features of the BrewZilla is the false bottom protection screen. This screen avoids the need for doing a whirlpool, filtering wort as it transfers and blocking more than 95% of hops and hot break from getting sucked into the pump. This not only prevents blocked pump issues, it also increases the efficiency of your brewhouse by eliminating kettle loss from wort that may have otherwise been left behind.
Ultra Low Watt Density Elements
The concave base on the BrewZilla also allowed for larger heating elements with significantly lower watt density than other breweries. When a lot of energy is coming off of a small element, the local temperature near the element can be so high that it scorches the wort and causes caramelization. Lower watt density essentially means you can produce lighter color beers that would otherwise have fallen victim to caramelization effect. It also reduces that chance of boilovers and reduces stress on the elements which extends their life expectancy.
Easy Access Built-In Pump
The built-in pump allows you to recirculate your wort during the mash for improved efficiency and more even temperature distribution. But it can also be used to transfer your wort from kettle to fermenter rather than relying on a gravity feed, and with the optional CIP Rotar, you can used the pump to clean your BrewZilla (or fermenter) after every use. During your brew day you’ll be able to control the pump from the RAPT Controller with a dedicated button for turning the pump on and off. Another feature you’ll find on the controller is adjusting the pump flow. This doesn’t control the actual volume of the flow (you can do that from the ball valve located on the recirculation arm), but rather cycles the pump on and off automatically based on your setting. At 100%, the pump remains on continuously. But at 80%, the pump will cycle to be on 80% of the time and off 20% of the time. This may not be a feature that every brewer thinks they need, but it’s an excellent way to avoid running the pump dry accidentally, as the time the pump is off allows recirculating wort to filter through the grain bed and back into the pump inlet.
If you flip over the boiler, you’ll find the magnetic drive pump and all the plumbing is right at your fingertips. This means you don’t have to disassemble the base in order to access the pump for cleaning or maintenance if required. It also means the plumbing can be changed more easily too. For instance, the unit comes as standard with the plumbing from the pump feeding both the recirculation arm and the transfer valve, but you change this so the tap outlet bypasses the pump if you prefer.
MoreBeer!'s Final Word
We’ve been selling all-in-one brewing systems ever since they first hit the market, and we have to say that the Gen 4 BrewZilla is not only the most feature-packed unit ever made, it’s also offered at an incredibly competitive price point when compared to other systems. You’ll get all of the cutting edge Bluetooth technology you’d get with the Grainfather and at an exceptionally lower price tag. Plus, you get the WiFi capabilities as standard, rather than as a $100 add-on accessory. When it comes to mash recirculation, that’s yet another built-in feature on the BrewZilla, and the pump can also be used for transferring and CIP cleaning. The Foundry has a great starting price, but if you want to unlock its full potential, you’ll need to spend another $100 for the recirculation pump kit. What’s more, no other system in the same ‘weight class’ has the same grain capacity. And if the standard capacity isn’t quite enough, the BrewZilla can be easily upgraded with a Boiler Body Extension Kit and Extended Malt Pipe. When you purchase the BrewZilla, you can feel confident that you’re investing in a top shelf system and all of the critical features you’re expecting will be included.
Perfect for Distillation
If you want to expand your lineup of homemade libations to offer Spirits in addition to Ales & Lagers, the BrewZilla makes an excellent pot still! Add the Distillation Lid upgrade and pair it with an AlcoEngine Copper Reflux Condenser or Copper Pot Still Top. AlcoEngine Stills have been selling on the home market for years and offer some of the most affordable, beginner-friendly stills you'll find.
Features:
Gen 4.1
Stainless steel construction
9 gallon total capacity with a finished beer output of 5-6 gallons
WiFi/Bluetooth Enabled RAPT digital temperature controller
Automatic step mashing with 6 programmable stages
220-240V power
NEMA 6-30P plug
Requires NEMA 6-30R receptacle
Requires 11 amps from 30 amp circuit
Dual heating elements (1900 watts and 500 watts)
Stainless steel 1/2" ball valve for gravity draining or transferring via pump
Immersion wort chiller included
Stainless steel malt pipe/basket
Stamped in volume markers
Glass lid
Adjustable lid clamps (do not use with glass lid in place - see below)
Magnetic drive pump for recirculation, transfers, and cleaning
Recirculation arm
PPSU sight glass
Bottom handle for easy lifting and pouring
Rubber feet
Temperature reads in °F or °C
Approximately 32.75" H (with recirculation arm) x 12.5" D
Recommended max. grain bill: 23.5 lbs
AlcoEngine Still ready with the purchase of a Distillation Lid
Pump Specs:
Max Capacity: 2.9–3.1 gal/min
Max Head: 4.9–6.8 ft.
Poles: 2
Voltage: 220–240V-AC
Frequency: 50–60Hz
Power: 6 watts
Current: 60 mA
Speed: 2600–3000rpm
Duty Cycle: Continuous
Capacitor: 2µF
Input/Output: 13mm barb
Water Resistance: IPX2
Please note: due to patent restrictions in the United States, the malt pipe has been redesigned with one set of bottom feet. This model does not include the "two stage" malt pipe as advertised by KegLand and featured in previous MoreBeer! YouTube videos.
Please Note: When removing the malt pipe to drain after mashing, it is important to do so slowly rather than in one swift pull. If the malt pipe is removed all at once when it is full of wort, it is possible for the draining wort to spray out and over the rim of the brewery through the perforated bottom. Remove the malt pipe slowly so that some of the wort can drain out before it is fully removed and set on its bottom feet. This can be done by hand on the 35L unit, but for the 65L and 100L units we highly recommend using the Pulley System for removing the malt pipe.
Warning: Do not engage the adjustable lid clamps when brewing with the BrewZilla's standard glass lid. The clamps are only intended to be used with distillation lids or other metal accessories. With too much tension, it is possible for the lid clamps to break the glass lid when engaged.
Warning: If you are going to use an extension cord with the BrewZilla, you must ensure that the cord is the correct gauge and properly rated to suit the power requirements of your brewery. See the reference chart below for the recommended gauge based on your unit and the length of cord you wish to use.
35L (110V)
35L (220V)
65L (220V)
100L (220V)
10 ft.
14 Gauge
14 Gauge
12 Gauge
10 Gauge
25 ft.
14 Gauge
14 Gauge
12 Gauge
10 Gauge
50 ft.
12 Gauge
12 Gauge
10 Gauge
8 Gauge
FermZilla Tri-Conical Easy-Grip Fermenter
A best seller for a reason! Tons of features at an incredible cost
Crystal Clear super smooth PET makes fermenting and cleaning super easy
3" Butterfly valve at bottom makes removing yeast/trub easy with the 600mL collection jar.
Pressurizable for fermentation and closed transfer to your keg
Includes BlowTie spunding valve kit, red & yellow carbonation caps, and floating dip tube as standard
The FermZilla is the perfect option for brewers that want all the advantages of a conical fermenter without the price tag of a full-blown stainless-steel unit. It allows you to dump trub, harvest yeast, and with the addition of CO2 cylinder and regulator, you can carbonate and serve – all in one vessel! The clear PET tank allows you to visually monitor fermentation activity and is pressure rated to 2.4 Bar (34.8 psi), which means you can ferment under pressure, reducing ester and fusel alcohols in your finished beer. This also gives the ability to perform pressure transfers. If you prefer to move your finished beer to a keg or other vessel, you can do so with little to no oxygen exposure.
The FermZilla Tri-Conical Easy-Grip model comes packed with accessories so you can take full advantage of this pressurizable fermenter on day one. The new stock standard includes Easy-Grip threaded lid ring, BlowTie spunding valve with integrated pressure gauge, ball lock carbonation caps for the lid and collection container, floating dip tube kit with weighted filter, volume marker graduation sticker, and adhesive thermometer.
What's Included:
FermZilla 27L Tank with 3" T.C. Bottom Port
Easy-Grip Threaded Lid Ring
Integrated Gauge BlowTie Kit Spunding Valve (0-15 psi)
Silicone Dip Tube Kit with Yellow Weighted Filter and SS Float
(2) Yellow Liquid Carbonation Caps
(2) Red Gas Carbonation Caps
Fermzilla Pressure Lid with Red PRV (35 psi)
3" T.C. Butterfly Valve
600 mL Collection Container with 3" T.C. Connection
Stainless Steel Stand with Swing Handles
3" tri-clamp with gasket
Graduation Sticker
Adhesive Thermometer
Specs:
27 L (7.1 gal) Total Volume
Pressure Rated to 2.4 Bar (34.8 psi)
Height in Stand - 30.2"
Tank Diameter - 13.9"
Diameter in Stand - 15.3"
Lid & Collection Container Ports - 28 mm PCO 1881 threads
Temperature Rating:
When not under pressure, do not expose to liquids above 131°F
When under pressure, do not expose to any temperatures above 95°F*
*Please note that the temperature rating for the FermZilla tank is lower when using it under pressure. When not under pressure, it is perfectly safe to transfer wort into the tank below 131°F or to use hot liquids below this temp for cleaning. When under pressure, make sure to keep your fermentation temperature below 95°F and keep the fermenter in an environment that is below 95°F ambient. This is especially important when fermenting with kveik yeast. These strains are known to ferment hot if no temperature control is being used. Exceeding the temperature rating may compromise the tank, leading to a shorter life span or sudden failure to maintain pressure. Even with proper use, we recommend replacing the tank every two years.
Please note: when using the FermZilla under pressure, you must perform a water pressure check to ensure your connections are leak proof. To do this, fill your FermZilla up with water, apply at least 15 psi pressure, and check for leaks around all caps and threads.
Pressure Stress
If you use the FermZilla to ferment under pressure, or you use CO2 to pressure transfer or force carbonate your finished beer, it is very important that you conduct semi-annual inspections of your tank. Even with perfect care, the FermZilla tank may show signs of wear from pressure stress over time. We recommend visually inspecting your tank for stress creases or other signs of wear once or twice a year. A hydro test should be conducted every two years, even if no signs of wear are found. The process is simple:
Fill the tank to the brim with water
Replace the Red PRV with a Green PRV rated to 4.5 BAR or higher
Pressurize the tank to 4 BAR (58 psi)
Check for leaks, then replace the Red PRV when finished
If leaks or potential points of failure are found, replace the tank before you continue using pressure with your FermZilla.
General Care
Taking good care of your FermZilla begins with cleaning and sanitizing the unit before and after use. The tank is made from food-grade PET, which is beautifully clear, but can be sensitive to long soaks in cleaners and acid-based sanitizers. In general, we do not recommend leaving products like PBW or StarSan soaking in the tank for more than an hour. Extended soaks have the potential to degrade the PET material and shorten the lifespan of the tank.
KegLand Part number: KL47296
NOTE: FermZilla tanks are marked with a manufacturer’s “expiry date”. This does not indicate that the tank is bad after this date; it simply indicates that a hydro test may be in order. 2 years after production and every 2 years after first use, it is recommended that the tank be hydro tested to ensure the tank is holding pressure. You will also need the D1072 Green PRV to perform the test. If you do not plan to pressurize the fermenter, the test is not necessary.
FermZilla Tri-Conical 27L & 55L | User Guide
High temp silicone grip provides a cool touch even with hot liquids!
Ribbed grips allow quick comfortable tool-free operation
Fits all male 1/2" NPT and BSP fittings
6.35 mm Duotight compatible stainless steel elbow barb tail
The KegLand Stainless Steel Quick Connectors come with a heavy-duty silicone grip guard allowing comfortable and quick tool-free operation.
Specs:
Stainless steel and silicone construction
Silicone O-ring seal is retained for perfect positioning but is easily cleaned or replaced
1/4" (6.35mm) OD elbow barb tail
KegLand Part Number: KL31677
Strong new base for your FermZilla All Rounders! Comes with sticky dots to keep it firmly attached to your fermenter. Super easy to install!
If you have the Gen 3.2 FermZilla All Rounder, you can purchase the Hex Base and Easy-Grip Threaded Lid Ring to upgrade your fermenter. This makes it easier to pick up and move the fermenter and eliminates the need for the Stand Harness.
KegLand Part Number: KL47333
Hoffman Clamps, or screw compressor clamps, are used to control the flow in flexible tubing. The clamp has a machined adjustment screw to permit accurate regulation of the flow. All corners are rounded to prevent cutting of the tubing.
This can be particularly useful when regulating the flow of sparge water, collecting sweet wort from your mash tun, or liquid management applications of a still.
Max Tubing OD: 30mm / 1.18"
KegLand Part Numbers: KL37891
Force carbonate and dispense from your KegLand Mini Keg
Low profile design minimizes overall height to help fit your keg in a cooler or compact refrigerator
Includes Gas-In and Bev-Out Ball Lock Caps for quick and easy attachment of ball lock disconnects
Dip tube filter attachment blocks sediment so you pour the clearest beer possible
Force carbonate and serve from your KegLand Mini Keg with the Low Profile Ball Lock Tapping Head. The Low Profile Tapping Head only adds approximately 1.5" to the overall height of the keg, making it the ideal dispensing solution if you need to fit your keg into a cooler or compact refrigerator. Includes PRV rated to 35 PSI and Gas-In and Bev-Out Ball Lock Caps for quick and easy attachment of ball lock disconnects. The filtered dip tube will block any sediment inside the keg so you'll be pouring the clearest beer possible.
If you'd prefer stainless steel keg posts over the plastic Ball Lock Caps, see the standard Ball Lock Tapping Head.
KegLand Part Number: KL24822
Perfectly sized for use with water lines—step down the pressure of your mains for use with water filtration systems Built-in pressure gauge for easy reference when adjusting pressure settings Pressure gauge is interchangeable—swap to different pressure ranges that better suit your application Compatible with both liquid and gas 6.35 mm Duotight inlet/outlet for use with 6.35 mm OD PE Water Line or EVABarrier tubing The Duotight In-Line Regulator works with both gas and liquid. Easily adjust the flow can be adjusted with the yellow adjustment knob. 6.35 mm Duotight fittings at both inlet and outlet make this unit perfect for use with 6.35 mm OD tubing (D1723C or D1727C). Features an integrated pressure gauge so you can quickly and easily dial in your pressure setting. The analog gauge is removable and can be swapped out with a gauge of a different pressure range or it can be swapped out for the Digital Mini Pressure Gauge. The size of the Duotight connection and the extended 0-150 PSI pressure range makes this model perfect for stepping down the pressure of your mains water line for use with water filtration or RO systems. Specifications:
Made from food grade acetal Stainless screws Easily disassembles for cleaning 6.35mm (1/4") Duotight fittings at both ends Interchangeable pressure gauge Gauge reads from 0-150 psi Made with quality EPDM seals Wall mountable WARNING: Do not exceed gauge pressure. Exceeding the pressure range will damage the gauge. Kegland Part number: KL26918
Designed for use with the PCO38 Tapping Head. With female PCO1881 threads, it can also be used with the FermZilla Collection Container or Hop Bong Sight Glasses. The Red PRV is rated to 35 psi (2.5 BAR). Warning: Never exceed the pressure capabilities of your vessel. PRV's are not spunding valves! KegLand Part Number: KB10537
This Duotight fitting with 1/2" male thread is perfect for attaching to the Copper Counterflow Chiller (WC130) and using with 1/2" female threaded Camlock and QD fittings. Compatible with EVABarrier 9.5 mm OD tubing (D1719). Duotight fittings are high-quality push-in fittings that seal tight and offer superior sealing capacity due to the double O-ring sealing design. High Performance Double O-Ring Design:
The secret to Duotight’s superior sealing performance comes from the fact that they use not one, but two high-quality EPDM O-rings. The double O-ring means they have literally twice the sealing surface when compared with other push-in fittings. This makes them more reliable and significantly reduces the chance of leakage. The double O-ring system also means that tubing can be bent at a much tighter radius without causing leaking issues, which can be an issue with other fittings. This combination of factors makes Duotight the most reliable push-in fittings on the market. EPDM offers excellent chemical resistance for a longer life span. When compared with silicone and vinyl, EPDM has much better gas transmission rates, better wear resistance, and is BPA-free. No Clamps Necessary!
We recommend cutting your tubing straight, not on an angle, to ensure the line forms a complete seal. To remove the fitting simply push in the collet and the hose can be removed. Features:
Insert tubing and firmly push to connect Easily release tubing by pushing in the collet Suitable for both gas & beverage applications Made from food-grade acetal plastic Double O-rings made from highly chemical resistant EPDM Locking teeth made from stainless steel Pressure rated to 150 psi Temperature rated to 212°F (100°C) Please note: exposure to chlorine will degrade the acetal plastic and stainless steel these fittings are made from. Do not use in contact with bleach or other chlorinated cleaning chemicals. Kegland Part number: KL06927
This Duotight elbow fitting is compatible with EVABarrier 9.5 mm OD tubing (D1719). Duotight fittings are high-quality push-in fittings that seal tight and offer superior sealing capacity due to the double O-ring sealing design. High Performance Double O-Ring Design:
The secret to Duotight’s superior sealing performance comes from the fact that they use not one, but two high-quality EPDM O-rings. The double O-ring means they have literally twice the sealing surface when compared with other push-in fittings. This makes them more reliable and significantly reduces the chance of leakage. The double O-ring system also means that tubing can be bent at a much tighter radius without causing leaking issues, which can be an issue with other fittings. This combination of factors makes Duotight the most reliable push-in fittings on the market. EPDM offers excellent chemical resistance for a longer life span. When compared with silicone and vinyl, EPDM has much better gas transmission rates, better wear resistance, and is BPA-free. No Clamps Necessary!
We recommend cutting your tubing straight, not on an angle, to ensure the line forms a complete seal. To remove the fitting simply push in the collet and the hose can be removed. Features:
Insert tubing and firmly push to connect Easily release tubing by pushing in the collet Suitable for both gas & beverage applications Made from food-grade acetal plastic Double O-rings made from highly chemical resistant EPDM Locking teeth made from stainless steel Pressure rated to 150 psi Temperature rated to 212°F (100°C) Please note: exposure to chlorine will degrade the acetal plastic and stainless steel these fittings are made from. Do not use in contact with bleach or other chlorinated cleaning chemicals. Kegland Part number: KL07030
Seamless Conversion: Easily adapts 6.35mm EVABarrier tubing to any 8mm female Duotight fitting.
Manifold Ready: Optimized for Duotight Gas Manifolds to facilitate quick-disconnect gas line setups.
Leak-Free Connection: Precision-engineered for a secure, airtight seal using standard Duotight push-fit technology.
This reducer allows you to attach 6.35mm EVABarrier tubing to any 8mm female Duotight fitting. This fitting is recommended for use with the Duotight Gas Manifold, allowing you to connect a Red Ball Lock QD Cap to the manifold for a convenient quick disconnect install on your Gas-In line.
High Performance Double O-Ring Design:
The secret to Duotight’s superior sealing performance comes from the fact that they use not one, but two high-quality EPDM O-rings. The double O-ring means they have literally twice the sealing surface when compared with other push-in fittings. This makes them more reliable and significantly reduces the chance of leakage.
The double O-ring system also means that tubing can be bent at a much tighter radius without causing leaking issues, which can be an issue with other fittings. This combination of factors makes Duotight the most reliable push-in fittings on the market.
EPDM offers excellent chemical resistance for a longer life span. When compared with silicone and vinyl, EPDM has much better gas transmission rates, better wear resistance, and is BPA-free.
No Clamps Necessary!
We recommend cutting your tubing straight, not on an angle, to ensure the line forms a complete seal. To remove the fitting simply push in the collet and the hose can be removed.
KegLand Part Numbers: KL42642
High temp silicone grip provides a cool touch even with hot liquids!
Ribbed grips allow quick comfortable tool-free operation
Fits all male 1/2" NPT and BSP fittings
8 mm Duotight compatible stainless steel barb tail
The KegLand Stainless Steel Quick Connectors come with a heavy-duty silicone grip guard allowing comfortable and quick tool-free operation.
Specs:
Stainless steel and silicone construction
Silicone O-ring seal is retained for perfect positioning but is easily cleaned or replaced
5/16" (8mm) OD barb tail
KegLand Part Number: KL31615
Oxygen-Free Dry Hopping: Designed to allow dry hopping without exposing the batch to oxygen. Customizable with Accessories: Features undrilled ports for optional accessories such as the Temp Twister Cooling Coil and Thermowell, enhancing functionality and convenience. Improved WiFi Reading: The plastic lid improves KegLand RAPT Pill WiFi reading, ensuring better connectivity. Compatible with all Kegmenter Fermentation Kegs with 4" Tri-Clamp ferrule. The Hop Bong is a versatile pressurizable tri-clamp accessory, capable of not only dry hopping oxygen purged hops into fermenters, but also as an inline carbonation/oxygenation accessory. Load up the Hop Bong, flush it with CO2, purge out oxygen with the handy PRV on top, then simply open the Butterfly Valve to inject your beer with a 6 oz payload of dry hops. This kit includes the 4" T.C. Pressure Lid to fit the tri-clamp ferule on Kegmenter Fermentation Kegs. The plastic lid also allows for improved KegLand RAPT Pill WiFi reading compared to the Kegmenter fully encasing the Pill in stainless steel. Due to the large 4" tri-clamp diameter, it is difficult to get higher pressures without leaking. Therefore we suggest using this up to 21 psi. The included Yellow PRV for the Pressure Lid is rated to 17 psi. The 3 Pieces of the Hop Bong Pressure Pack: Pressure Kit The Pressure Kit includes two Ball Lock Caps for Gas & Liquid. The Liquid cap can be paired with the optional Floating Dip Tube and Filter Attachment. These pieces allow you to pressure transfer finished beer out of the fermenter into kegs or a bottling bucket, or you can carbonate and serve beer directly from the Kegmenter. Tri-Clamp Pressure Lid Replacing the standard lid with the Tri-Clamp Pressure Lid provides you with a 2" T.C. port at the top of your fermenter. This will give you an opening to add dry hops or other additions without needing to remove the entire lid. Take off the butterfly valve to add your yeast pitch, and when you're ready to add flavoring additions when fermentation is complete, drop them in oxygen-free via the Hop Bong. PCO1881 threaded ports are there for your Ball Lock Caps, as well as undrilled ports for an optional Thermowell and/or Temp Twister cooling coil. Hop Bong Load up the Hop Bong and add CO2 to purge your hop charge of oxygen. This kit comes with a third Ball Lock Cap to introduce CO2 directly to the Hop Bong, as well as a pull ring PRV to release pressure and purge oxygen. Once you've flushed your hop charge with CO2, open the butterfly valve to inject your beer with up to 6 oz of hop pellets. Hop Pellet Capacity: 150–180g (5.2–6.3 oz) Kit Includes: Kegmenter 4" T.C. Pressure Lid 2" Hop Bong 2" Butterfly Valve Red PRV & PCO1881 Cap Combo Yellow PRV Yellow Ball Lock Cap (2) Red Ball Lock Caps (3) 2" Tri-Clamps (3) 2" Silicone T.C. Gaskets Optional Accessories: Floating Dip Tube (FE115A) Filter Attachment (KEG657) Available Kegmenters:
7.6 Gallon (FE582) 13.2 Gallon (FE584) 15.3 Gallon (FE581) 1 bbl (FE585) KegLand Part Number: KB23665 Warning: Always depressurize your system COMPLETELY before removing fittings from your fermenter.
NOTE: This accessory is designed exclusively for 3-vessel brewers who want to use the BrewZilla or DigiBoil as a mash tun. It is not meant to be used alongside a malt pipe, and it is not intended to be an upgrade or replacement to the BrewZilla's standard false bottom protection screen.
If you're a 3-vessel brewer and want to use the BrewZilla or DigiBoil purely as a mash tun, this is false bottom will give you more volume compared to mashing with a malt pipe. Designed for use with DigiBoil electric kettles or BrewZilla all-in-one systems. Unlike two-piece false bottoms you may find, this unit is welded together for maximum strength. It will easily withstand as much grain weight as you could possibly fit in the vessel. Features welded handles to easily remove the false bottom when cleaning.
Compatible with 35L DigiBoils and Gen 3/4 35L BrewZillas.
Dimensions:
Diameter: 11.61" (295 mm)
Height: 1.77 (45 mm)
Approximate Dead Space: 0.79 gal (3 L)
KegLand Part Number: KL27700
Replacement PET Tank for the 55L Tri-Conical FermZilla with tri-clamp bottom port. Perhaps your wort was too hot when you transferred from the kettle, or while cleaning you dropped the FermZilla against something sharp that punched a hole, or maybe it's just time to replace the tank after acquiring too many scratches from normal wear-and-tear. Whatever the reason, no need to go buy a whole new FermZilla! Just pick up one of these fresh replacement tanks and your conical fermenter will be good as new! Pressure Stress If you use the FermZilla to ferment under pressure, or you use CO2 to pressure transfer or force carbonate your finished beer, it is very important that you conduct semi-annual inspections of your tank. Even with perfect care, the FermZilla tank may show signs of wear from pressure stress over time. We recommend visually inspecting your tank for stress creases or other signs of wear once or twice a year. A hydro test should be conducted every two years, even if no signs of wear are found. The process is simple: Fill the tank to the brim with water Replace the Red PRV with a Green PRV rated to 4.5 BAR or higher Pressurize the tank to 4 BAR (58 psi) Check for leaks, then replace the Red PRV when finished If leaks or potential points of failure are found, replace the tank before you continue using pressure with your FermZilla. General Care Taking good care of your FermZilla begins with cleaning and sanitizing the unit before and after use. The tank is made from food-grade PET, which is beautifully clear, but can be sensitive to long soaks in cleaners and acid-based sanitizers. In general, we do not recommend leaving products like PBW or StarSan soaking in the tank for more than an hour. Extended soaks have the potential to degrade the PET material and shorten the lifespan of the tank. KegLand Part Number: KL28257 NOTE: FermZilla tanks are marked with a manufacturer’s “expiry date”. This does not indicate that the tank is bad after this date; it simply indicates that a hydro test may be in order. 2 years after production and every 2 years after first use, it is recommended that the tank be hydro tested to ensure the tank is holding pressure. Hydro test instructions are available here. You will also need the D1072 Green PRV to perform the test. If you do not plan to pressurize the fermenter, the test is not necessary.
Perfect for serving your craft creations on the go or making a compact home draft system that fits inside your refrigerator
Welded from the inside out using a specialized technique for superior, more sanitary welds compared to similar mini kegs
Interlocking chimes for easy and secure stacking of multiple mini kegs
KegLand's Small Stainless Steel Mini Beer Kegs are ideal for homebrewing small batches and serving your craft creations directly from your home fridge. These compact kegs are designed for convenience and versatility.
Flexible Dispensing and Carbonation
You can naturally carbonate your beer using priming sugars or, for a more controlled approach, force carbonate and serve with the Ball Lock Tapping Head. The Tapping Head features a flexible silicone dip tube, allowing you to dispense beer whether the keg is standing upright or lying on its side. The dip tube will sink and draw liquid from the bottom, allowing you to orient the keg whichever way is more convenient in your refrigerator.
Superior Quality and Durability
KegLand's mini kegs are built to last, undergoing acid bath electrolysis to passivate the stainless steel, making them exceptionally resistant to rust. These are the only mini kegs on the market that are welded from the inside out using a specialized technique. This results in a superior, more sanitary welding finish compared to other mini kegs. When you choose a KegLand mini keg, you're investing in the highest quality available, surpassing the standards of other mini kegs of similar design.
Low2 Lid O-Ring
The sealing cap features an O-ring made of KegLand's special Low2 material which offers vastly improved oxygen barrier properties compared to silicone or EPDM, resulting in your beverage staying fresher for longer.
Expand Your Setup with Accessories
Enhance your mini keg experience with a range of available accessories, including neoprene jackets for insulation and compact tapping systems for easy dispensing.
Stackable with the 2L Mini Keg.
Specs:
4L / 1 Gal / 135 fl oz
11" High x 5.3" Diameter (280mm x 135mm)
Max Working Pressure: 45 PSI / 3 Bar
Made from 304 Stainless Steel
KegLand Part Number: KL06354
If you're tired of losing gas every time you connect or disconnect your Sodastream cylinder to your normal Sodastream cylinder adapter, this new design is what you need. Unlike cheaper Sodastream cylinder adapters, this unit has the added advantage that you can use the side thumb screw to depress the pin in the middle of the adapter. This pin adjustment makes the Sodastream cylinder adapter significantly easier to use.
Some adapters require an Alan Key wrench to adjust the pin height, and depending on how worn out your seal is, you may need to adjust this pin periodically. Conventional, cheaper Sodastream adapters also tend to leak gas every time you connect and disconnect them from your regulator or the adapter itself.
If you have a Sodastream Cylinder, you can use this adapter to connect it to a CGA320 CO2 Regulator. This is a great choice for mobile draft applications when you don't want to carry around your home draft system's 5 lb or larger CO2 tank.
CGA320 Male Thread x TR21-4 Female Thread
NOTE: Does not include CO2 regulator or Sodastream Cylinder seen in the example photos.
KegLand Part Number: KL24662
This stainless steel ball lock cap features soda bottle threads, allowing you to convert a 1 or 2 liter soda bottle into a convenient travel growler. The ball lock is compatible with both gas and beverage disconnects, so you can charge the PET bottle before you leave the house and dispense on the go. Use the Duotight compatible stem to connect a 8mm or 9.5mm reducer, then attach EVABarrier draft line to serve as your dip tube and you're all set! These caps also work great for quickly and conveniently cleaning your draft lines. Mix up a small batch of line cleaning solution in a soda bottle, attach the ball lock cap, and then connect it to your beverage line. Place a bucket below your tap to catch the cleaning solution and open your faucet. Then simply turn the bottle upside down and squeeze it to push solution through your line and out the faucet. You can also choose to pressurize the bottle first, but squeezing the solution through is just as effective. Fermenting with the FermZilla? This is ball lock fitting is also compatible with the FermZilla Collection Container. If you use the collection container to add dry hops, attach one of these caps and you'll be able purge the container of oxygen before opening the dump valve to introduce the hops. Attach some tubing and diffusion stone and you can oxygenate your wort through the collection container as well! Features: 6.5mm Duotight Compatible Liquid and Gas Ball Lock Compatible Disassembles for Easy Cleaning Made from Stainless Steel 28mm PCO 1881 Threads Please note: The threaded section of the bottleneck must be at least 1/2" long to form a seal. These caps are not compatible with the KegLand 500mL PET Bottles. Kegland Part Number: KL20435
This Duotight fitting is designed to go through the wall of a tank, housing, or wall, similar to a pass through shank, so you can run EVABarrier tubing from one side to the other. Compatible with EVABarrier 8 mm OD tubing (D1717 / D1718). With the lock nuts in place, there is approximately 1" of pass through threading. Duotight fittings are high-quality push-in fittings that seal tight and offer superior sealing capacity due to the double O-ring sealing design. High Performance Double O-Ring Design:
The secret to Duotight’s superior sealing performance comes from the fact that they use not one, but two high-quality EPDM O-rings. The double O-ring means they have literally twice the sealing surface when compared with other push-in fittings. This makes them more reliable and significantly reduces the chance of leakage. The double O-ring system also means that tubing can be bent at a much tighter radius without causing leaking issues, which can be an issue with other fittings. This combination of factors makes Duotight the most reliable push-in fittings on the market. EPDM offers excellent chemical resistance for a longer life span. When compared with silicone and vinyl, EPDM has much better gas transmission rates, better wear resistance, and is BPA-free. No Clamps Necessary!
We recommend cutting your tubing straight, not on an angle, to ensure the line forms a complete seal. To remove the fitting simply push in the collet and the hose can be removed. Features:
Insert tubing and firmly push to connect Easily release tubing by pushing in the collet Suitable for both gas & beverage applications Made from food-grade acetal plastic Double O-rings made from highly chemical resistant EPDM Locking teeth made from stainless steel Pressure rated to 150 psi Temperature rated to 212°F (100°C) Please note: exposure to chlorine will degrade the acetal plastic and stainless steel these fittings are made from. Do not use in contact with bleach or other chlorinated cleaning chemicals. KegLand Part Number: KL21036
The Ultimate BrewZilla Combo Pack! Get the Gen 4 BrewZilla & our most highly recommended accessories at an unbeatable price! Includes all of our favorite accessories for the BrewZilla including the Neoprene Jacket to speed up heating times, Hop Spider to keep vegetal matter out of your wort, and Chilling Connection Kit so you're ready to use the Immersion Chiller out of the box We think all BrewZilla brewers will eventually upgrade their systems with these accessories, so buy them together and reap the savings! Also available in 110V (AG581)
Combo Pack Includes: BrewZilla Brewing System | Gen 4 | 9.25G | 220V Neoprene Jacket Hop Spider Wort Chiller Connection Kit Gen 4 BrewZilla All-in-One Brewing System WiFi / Bluetooth enabled RAPT Controller tracks your brewday and automatically uploads detailed information to the RAPT portal The top mounted RAPT Controller can be tilted upward for easy viewing, or detached from the unit to mount it on the wall or placed on your bench Mirror polished dome shaped bottom with center drain — get every last bit of wort into your fermenter while the perforated bottom screen filters out 95% of hot break and hop matter Make larger batches or higher gravity beers! BrewZilla offers the largest malt pipe capacity for units in its size range, and the Gen 4 unit has a 30% larger malt pipe compared to the previous generation Perforated bottom on the newly designed malt pipe allows for improved mash recirculation flow without sacrificing efficiency Element power percentage can be adjusted via the RAPT Controller. Go full power to heat up quickly, or dial it down so you don’t overshoot your strike water temp The built-in pump is plumbed to both the recirculation and arm and the bottom ball valve. Recirculate wort during your mash, then close the recirculation valve and pump wort to your fermenter via the bottom valve Pair with the RAPT-enabled Bluetooth Thermometer, allowing your BrewZilla to calculate a core mash temperature reading and more accurately control temperatures and mash steps More RAPT-enabled accessories are coming, and future firmware updates can be downloaded to the RAPT Controller itself over the internet WiFi/Bluetooth Enabled RAPT Controller The RAPT Controller is mounted to the top of the boiler body, allowing for easy operation when you have the unit set on the ground. The controller can be tilted upwards to give you an even better view, or it can be removed from the BrewZilla entirely if you’d prefer to mount the controller on your wall or lay it down on a workbench. From the controller, you’ll orchestrate your entire brew day. Program mash steps, dial in element power, and operate the integrated pump all from one screen. But the RAPT Controller is much more than a beautiful, full-color display switch board. Once synced to the RAPT Portal, you’ll be able to track, record and monitor your brews online. No need for handwriting notes or punching brew day details into your phone – all of the data from your brew is automatically logged to your portal profile. This information doesn’t just include your mash profile; it also captures detailed information about your element power and pump activity, opening the door for very precise repeatability. And the RAPT Portal isn’t just a digital archive for your brew days. With your BrewZilla powered on, you can control your brewery from virtually anywhere using your phone’s web browser. Not sure when you’ll be home from work or your kid’s ball game going into extra innings? No problem! Before you head out, simply log into the RAPT Portal from your phone and tell the BrewZilla to start heating your strike water. Along with remote control, the portal enables you to program alarms and push notifications for all of your boil additions. We’ve all been caught up with a side task and failed to throw in that yeast nutrient or clarifying agent at the end of the boil, but the BrewZilla has the back of even the most forgetful brewer! But wait, there’s more! In addition to WiFi connectivity, the RAPT Controller is also a Bluetooth gateway device. KegLand is currently developing various Bluetooth devices such as the Bluetooth Beacon Thermometer and other sensors which will be compatible with your brewery upon release. The RAPT Controller is able to receive information from Bluetooth Low Energy (BLE) devices, adjusting its processes based on this new stream of information while simultaneously logging it to your RAPT Portal. With the Bluetooth Beacon Thermometer, for example, you’ll be able to feed temperature readings from the top of your mash bed to the controller. The controller will then compare this reading with the main temp probe reading at the base of the kettle and adjust element cycling based on these combined readings. Finally, the RAPT Controller WiFi connectivity allows you to update the controller’s firmware with a single click. Take advantage of new features and accessories as soon as they become available by simply keeping your BrewZilla connected to your local WiFi network. And again, the WiFi is already built-in! No need to come back for an expensive add-on accessory down the road. High Capacity Malt Pipe With an approximately 23.5 lb capacity, the BrewZilla can mash nearly 50% more grain than similar sized models of the Anvil Foundry and Grainfather G30. If you want to fill your fermenter with more than a 5-gallon batch worth of wort, or brew the highest gravity beer recipes, the BrewZilla is the brewhouse for the job. And the included malt pipe is just the beginning. If you want to expand your brewery’s grain capacity even further, KegLand makes Boiler Extension Kits and Extended Malt Pipes for that very purpose. The malt pipe features a perforated section at the bottom which improves mash recirculation flow without sacrificing efficiency. Concave Base with Center Draining Leave no wort behind! The concave base with center drain means you’ll be able to extract every last drop of wort to your fermenter. If you’ve brewed in a traditional flat bottom kettle, this center drain may be a bit perplexing at first. Many brewers are used to whirlpooling after the boil to pull hop matter into the center of the kettle, then transfer out using a pick-up tube that pulls from the kettle wall in order to avoid sucking up the solids. But fear not! One of the key features of the BrewZilla is the false bottom protection screen. This screen avoids the need for doing a whirlpool, filtering wort as it transfers and blocking more than 95% of hops and hot break from getting sucked into the pump. This not only prevents blocked pump issues, it also increases the efficiency of your brewhouse by eliminating kettle loss from wort that may have otherwise been left behind. Ultra Low Watt Density Elements The concave base on the BrewZilla also allowed for larger heating elements with significantly lower watt density than other breweries. When a lot of energy is coming off of a small element, the local temperature near the element can be so high that it scorches the wort and causes caramelization. Lower watt density essentially means you can produce lighter color beers that would otherwise have fallen victim to caramelization effect. It also reduces that chance of boilovers and reduces stress on the elements which extends their life expectancy. Easy Access Built-In Pump The built-in pump allows you to recirculate your wort during the mash for improved efficiency and more even temperature distribution. But it can also be used to transfer your wort from kettle to fermenter rather than relying on a gravity feed, and with the optional CIP Rotar, you can used the pump to clean your BrewZilla (or fermenter) after every use. During your brew day you’ll be able to control the pump from the RAPT Controller with a dedicated button for turning the pump on and off. Another feature you’ll find on the controller is adjusting the pump flow. This doesn’t control the actual volume of the flow (you can do that from the ball valve located on the recirculation arm), but rather cycles the pump on and off automatically based on your setting. At 100%, the pump remains on continuously. But at 80%, the pump will cycle to be on 80% of the time and off 20% of the time. This may not be a feature that every brewer thinks they need, but it’s an excellent way to avoid running the pump dry accidentally, as the time the pump is off allows recirculating wort to filter through the grain bed and back into the pump inlet. If you flip over the boiler, you’ll find the magnetic drive pump and all the plumbing is right at your fingertips. This means you don’t have to disassemble the base in order to access the pump for cleaning or maintenance if required. It also means the plumbing can be changed more easily too. For instance, the unit comes as standard with the plumbing from the pump feeding both the recirculation arm and the transfer valve, but you change this so the tap outlet bypasses the pump if you prefer. MoreBeer!'s Final Word We’ve been selling all-in-one brewing systems ever since they first hit the market, and we have to say that the Gen 4 BrewZilla is not only the most feature-packed unit ever made, it’s also offered at an incredibly competitive price point when compared to other systems. You’ll get all of the cutting edge Bluetooth technology you’d get with the Grainfather and at an exceptionally lower price tag. Plus, you get the WiFi capabilities as standard, rather than as a $100 add-on accessory. When it comes to mash recirculation, that’s yet another built-in feature on the BrewZilla, and the pump can also be used for transferring and CIP cleaning. The Foundry has a great starting price, but if you want to unlock its full potential, you’ll need to spend another $100 for the recirculation pump kit. What’s more, no other system in the same ‘weight class’ has the same grain capacity. And if the standard capacity isn’t quite enough, the BrewZilla can be easily upgraded with a Boiler Body Extension Kit and Extended Malt Pipe. When you purchase the BrewZilla, you can feel confident that you’re investing in a top shelf system and all of the critical features you’re expecting will be included. Perfect for Distillation If you want to expand your lineup of homemade libations to offer Spirits in addition to Ales & Lagers, the BrewZilla makes an excellent pot still! Add the Distillation Lid upgrade and pair it with an AlcoEngine Copper Reflux Condenser or Copper Pot Still Top. AlcoEngine Stills have been selling on the home market for years and offer some of the most affordable, beginner-friendly stills you'll find. Features: Gen 4.1 Stainless steel construction 9 gallon total capacity with a finished beer output of 5-6 gallons WiFi/Bluetooth Enabled RAPT digital temperature controller Automatic step mashing with 6 programmable stages 220-240V power NEMA 6-30P plug Requires NEMA 6-30R receptacle Requires 11 amps from 30 amp circuit Dual heating elements (1900 watts and 500 watts) Stainless steel 1/2" ball valve for gravity draining or transferring via pump Immersion wort chiller included Stainless steel malt pipe/basket Stamped in volume markers Glass lid Adjustable lid clamps (do not use with glass lid in place - see below)
Magnetic drive pump for recirculation, transfers, and cleaning Recirculation arm PPSU sight glass Bottom handle for easy lifting and pouring Rubber feet Temperature reads in °F or °C Approximately 32.75" H (with recirculation arm) x 12.5" D Recommended max. grain bill: 23.5 lbs AlcoEngine Still ready with the purchase of a Distillation Lid Pump Specs: Max Capacity: 2.9–3.1 gal/min Max Head: 4.9–6.8 ft. Poles: 2 Voltage: 220–240V-AC Frequency: 50–60Hz Power: 6 watts Current: 60 mA Speed: 2600–3000rpm Duty Cycle: Continuous Capacitor: 2µF Input/Output: 13mm barb Water Resistance: IPX2 Please note: due to patent restrictions in the United States, the malt pipe has been redesigned with one set of bottom feet. This model does not include the "two stage" malt pipe as advertised by KegLand and featured in previous MoreBeer! YouTube videos. Please Note: When removing the malt pipe to drain after mashing, it is important to do so slowly rather than in one swift pull. If the malt pipe is removed all at once when it is full of wort, it is possible for the draining wort to spray out and over the rim of the brewery through the perforated bottom. Remove the malt pipe slowly so that some of the wort can drain out before it is fully removed and set on its bottom feet. This can be done by hand on the 35L unit, but for the 65L and 100L units we highly recommend using the Pulley System for removing the malt pipe. Warning: Do not engage the adjustable lid clamps when brewing with the BrewZilla's standard glass lid. The clamps are only intended to be used with distillation lids or other metal accessories. With too much tension, it is possible for the lid clamps to break the glass lid when engaged. Warning: If you are going to use an extension cord with the BrewZilla, you must ensure that the cord is the correct gauge and properly rated to suit the power requirements of your brewery. See the reference chart below for the recommended gauge based on your unit and the length of cord you wish to use. 35L (110V) 35L (220V) 65L (220V) 100L (220V) 10 ft. 14 Gauge 14 Gauge 12 Gauge 10 Gauge 25 ft. 14 Gauge 14 Gauge 12 Gauge 10 Gauge 50 ft. 12 Gauge 12 Gauge 10 Gauge 8 Gauge
This stainless steel butterfly hose clamp is perfect for use with braided/reinforced silicone tubing. The butterfly thumb screw allows for toolless tightening and untightening, so you can build out or break down your system without rummaging through the toolbox for the right screwdriver.
Fits 5/8" to 1.5" OD tubing. Actual size of the clamp is 21-38 mm (0.82" - 1.49").
KegLand Part Number: KL24440
This flat lid with pre-drilled holes allows you to easily add a Temp Twister Cooling Coil to your 35L Bucket Buddy fermenter. It also has holes for your stopper & airlock (included with the Bucket Buddy) as well as a Thermowell so you can control the circulation of cooling solution with a Temperature Controller. The lid is also compatible with 35L BrewZillas and DigiBoils. If you're fermenting in the Bucket Buddy with built-in heating element, we recommend plugging the unit into the heating outlet of your temperature controller and leaving the power switch turned on. This will allow the temp controller to provide power to the unit only when heating is needed and it will cut the power as soon as you're back to your set temperature. Using the Bucket Buddy's controller to maintain the heating set temp and using a separate controller to maintain the cooling may result in heating and cooling cycling at the same time. NOTE: The pre-drilled holes are meant for specific sizes of Duotight bulkheads and the stopper included with the Bucket Buddy fermenter. All holes need to be occupied in order to protect your fermentation from outside contaminants. Depending on the placement of the Temp Twister, you might need to shorten the inlet/outlet tubes on the outside of the fermenter using a Pipe Cutter. Lid only. Other accessories must be purchased separately. You Will Also Need: Temp Twister Cooling Coil FermZilla Thermowell Temperature Controller KegLand Part Number: KL28103
This 40 Liter Hydropress provides a simple, highly effective method of extracting juice from apples, pears, berries or grapes for juice, wine or cider making. It can also be used as a cheese press or for honeycomb. Primarily targeted at the Apple Mead and Cider makers, as this press is hard to beat on a budget. Make the best possible sparkling cider with the Electric Apple Grinder and 40L Hydropress.
Bladder presses work by expanding a rubber bladder using household water pressure via a garden hose. Since the bladder is situated in the center of the press, the grapes/fruit are squeezed from the inside out in a uniform fashion even if the basket is only partially filled. This is a much more effective way of pressing fruit pulp as it allows a wider surface area for the juice to be extracted. Compared to traditional hydraulic top down presses, large amounts of streaming and blockages would be trapped within the bulk matter. The hydropress is also used on a mammoth scale in wineries as it is by far the most effective means of extraction without electrical power.
When pressing normal mains water pressure of 2.5 to 3 bar it will generate around 20 tonnes of pressing power. The pressure applied and the duration of pressing can be regulated simply by opening or closing the water tap.
High-Quality Material
This water-powered press is made of food-grade stainless steel, resistant to rust and corrosion, easy to wash, and wipe clean after use. With three stable steel legs. Best suited to be used outdoors where you can hose away any accidental spills of fruit and juice.
Electricity-Free:
Bladder presses use water to produce pressure for natural juice making, winemaking and cheese making. It’s energy-saving and space-saving. If the pressure gets too high, it will be released automatically, making this unit safe and easy to operate.
Important:
Keep the gray bladder out of direct sunlight for storage. A black garbage bag makes an excellent cover that will protect your gear for years to come.
Features:
40L capacity
Rubber membrane is made of high-quality natural rubber
Food grade stainless steel perforated basket
Press bag included
Make grapes, apple, pears, cherries, tomatoes, berries, or other soft fruit into juice, cider or wine
Made of food grade 304 Stainless Steel
Easy to dismantle and clean
1/2" BSP Female water inlet
KegLand Part Number: KL23313
Duotight 6.35 mm OD retaining clip. Locks Duotight fittings in their closed position, making it impossible for any hose to escape. Pack of 10.
KegLand Part Number: KL21937
This Monotight check valve is a great idea for protecting your regulator. It has a low opening pressure of 1 psi, and since it cannot be opened or taken apart, it is recommended for gas applications only. The internal components are made from stainless steel. Compatible with EVABarrier 6.35 mm OD Tubing. Monotight brings the same superior quality as Duotight push-in fittings but more appropriately sized for applications including water treatment equipment, water filters, reverse osmosis fittings, and more. In addition, they are suitable for both beverage and gas applications, and are pressure rated to 100 psi. Tubing can be released by simply pushing in the collet and pulling the line out. No need for clamps or cutting lines! Features: Insert tubing and firmly push to connect Easily release tubing by pushing in the collet Suitable for both gas & beverage applications Made from food-grade acetal plastic O-rings made from highly chemical resistant EPDM Locking teeth made from stainless steel Pressure rated to 150 psi Temperature rated to 212°F (100°C) Please note: exposure to chlorine will degrade the acetal plastic and stainless steel these fittings are made from. Do not use in contact with bleach or other chlorinated cleaning chemicals. Kegland Part number: KL21968
Compatible with the 27L and 55L FermZilla Tri-Conical Series or any 2" or 3" T.C. fittings. This valve comes standard on the Tr-Conical FermZillas where the bottom of the tank attaches to the collection container.
KegLand Part Number: KL26505
This adapter can be installed on the Core 360 Mini Regulator from Kegland in order to use 74 gram CO2 cartridges. Use a crescent wrench to remove the stock adapter piece for 12 gram cartridges and simply screw in this adapter with 5/8-18 UNF female threading. Switching to 74 g cartridges will allow you dispense 1-4 Cornelius kegs, depending on how it is used and the CO2 consumption required. TR21-4 Male Thread x 5/8-18 UNF Female Thread Adapter only. Regulator and CO2 cartrdige sold separately. KegLand Part Number: KL2041
This simple pump kit is a great way to clean your draft lines when you don't want to waste CO2 or mix up a full batch of line cleaner. The PCO tee piece can be attached to a PET beer bottle or repurposed soda bottle, then pressurized with the hand pump to push cleaner through your ball lock disconnect and draft lines.
You can also use the pump kit to turn just about any PET bottle into a mini party keg; one that's easy to take with you while leaving your gas equipment at home. But since you'll be using air to push the beer out, we recommend consuming the contents of the bottle well within 24 hours.
Kit Contains:
Yellow carbonation cap
Red Tee Piece - 28mm PCO 1881 Threads (Female x Male x Male)
Mini yellow hand pump
11.75" length of EVABarrier tubing (5mm ID x 8mm OD)
PET Bottle not included
KegLand Part Number: KL20220
Pack up your HIZO Pizza Oven and feed hungry pizza fanatics wherever you journey
Waterproof. Functions as both a carry bag and a storage cover
The HIZO G14 Portable Gas-Fired Pizza Oven is the perfect no hassle solution to cooking the best homemade pizza outdoors. Fold down the legs of the HIZO G14 and tuck the gas hose underneath. Stretch out the carry bag and catch one end in under the adjustable string piece part and pull over the unit like you would a fitted sheet. There are a total of four clips on the underside. In a cross like pattern put the top left clip into the bottom right. Repeat with the top right to bottom left (refer to product photo if needed).
This carry bag / storage cover has been hot-seamed stitched together for maximum waterproofing.
KegLand Part Number: KL24891
This optional lid is a great accessory if you want a more convenient way to move your Flat Bottom FermZilla around. Includes a silicone grommet for your airlock pre-installed.
This unique FermZilla lid piece does not require thread tape, o-rings or washers to form an airtight seal.
Please Note: This lid is not pressure rated.
KegLand Part Number: KL20848
Plate heat exchangers are one of the fastest ways to cool your wort and the Chillout is one of the best. The Chillout MKIV, now with new and improved male 1/2" BSP threaded posts, is the fastest way to chill your wort to yeast pitching temperature to get your fermentation off to a quick healthy start. made from stainless steel and brazed together with pure copper. It also has ripples along each plate that create more surface area to improve heat transfer. A great addition to your brewing setup.
Set up one side with Wort in & out, and Water out & in on the other side.
Features:
Made from stainless steel and copper
Rippled plates for more surface area
1/2" Male BSP connections
Dimensions: 12.4" x 2.8" x 2" (not including threads)
KegLand Part Number: KL21234
Due to high demand, this item is currently out of stock. Be the first to receive your items by placing a pre-order today. We will automatically ship this to you when we receive more inventory.
Everything you need to have some fresh beer on the go. This ultimate growler is made from double wall, vacuum insulated stainless steel which makes it impervious to oxygen and sunlight. The included pressure lid allows you to pressurize the growler up to 30 psi with the provided mini CO2 regulator. The regulator uses 16 g threaded CO2 cartridges.
Includes:
2 L stainless steel growler
Pressure lid with plastic tap
Mini CO2 regulator
6 CO2 cartridges
Please note: due to air shipping restrictions, this product is only eligible for ground shipment within the contiguous United States.
Corny keg style pressure relief valve rater to 17 PSI
Lower the blow off pressure of kegs, regulators, fermenters, etc. for added operating safety
Replacement pressure relief valve rated to blow at 17 psi. This corny keg lid style PRV can be used with a range of products including kegs, FermZilla conicals, KegLand kegmenters, and KOMOS CO2 regulators. If you don't intend to ever exceed 17 PSI with the product you're using, installing the Yellow PRV will help ensure you don't over pressurize.
NOTE: This is a safety device designed to release pressure at the approximate rated pressure. This is not intended to be used as a Spunding Valve.
KegLand Part Number: KL22569
Comes with a back nut, plastic collar, hex nut, and a 1/4" barb. Requires a 1" hole saw for installation. When set in place, the shank will only have about 2 1/2" of length to pass through your wall or fridge door, due to the length of the collar and back nut.
Installation note: On a fridge there is generally no coolant lines running through the door but please check to see there are no lines connecting the door and the rest of the refrigerator. To test for coolant lines on a freezer start with a warm freezer then plug the unit in with the lid open. You should be able to see the lines form condensation on the inside of the freezer where there are lines running. Please still use caution when drilling.
Dimensions:
5-1/8" - Total Length (Tip to Tip)
4" - Shank Length (Without Nut & Barb)
3" - Thread Length
2-1/2" - Pass Through Length
Kegland Part number: KL01113
Replacement O-rings for the 1/2" KegLand Quick Swivel Connectors. Made from high temp silicone. Comes in a pack of 10.
These come in brown silicone only. Refrain from using undiluted acidic / heavy strength alkaline substances or the Silicone may change in color.
KegLand Part Number: KL31592
This super handy Solenoid Valve is compatible with 1/4" or 6.35 mm OD PE Water Line or EVABarrier tubing. This size tubing is often used on water filtering systems or reverse osmosis systems, and can be used with an Inline Regulator to drop your mains water pressure if needed. Unlike some other solenoid valves this is a direct acting solenoid valve meaning the solenoid valve can go down to 0 pressure. This makes it quite handy for controlling CO2 flow or other low-pressure gasses. Suitable for pressures up to 115 psi (8 bar) so it will handle water pressure with no problem at all. Made from high-quality metal and POM engineering plastics so it is durable and suitable for contact with a wide range of chemicals and beverages. Specs: Inlet/Outlet: 6.35 mm (1/4") Pressure Rating: 0-115 psi (0-8 Bar) Mode: Normally Closed (NC) Solenoid Coil Voltage: 12V Solenoid Coil Amp Draw: 1.1A KegLand Part Number: KL09478
This is a replacement heat proof graduation sticker for BrewZillas with the PPSU Sight Glass installed.
Choose your size of BrewZilla above for the appropriate graduation sticker.
For use with the 65L BrewZilla Boiler Extension Kit. It does not come with an extra Wire Malt Pipe Support Ring. If you're using the extended malt pipe with the 65L DigiBoil, you will need to purchase the ring separately. If you're using the malt pipe with the 65L BrewZilla you can either move your ring up to the boiler extension, or buy an additional ring so you can remove the malt pipe in two steps.
You will also need the Ricirculation Arm Extension to continue using the BrewZilla's recirculation arm.
Compatible with 65L Gen 3 / Gen 4 BrewZillas.
Example image of the 35L model shown here.
KegLand Part Number: KL32834
Convert 1" BSP fittings to 1.5" tri-clamp. Made from 304 stainless steel.
BSP vs. BSPP
BSP (or BSPT) fittings have a tapered thread and require teflon tape to form a seal between the male and female fitting. BSP fittings are generally intended to be used with their counterpart of the same thread type. ONLY 1/2" BSP fittings are compatible with US-standard NPT fittings of the same size. BSPP fittings, on the other hand, have a straight thread, require a gasket seated inside the female fitting to form a seal, and are not compatible with NPT.
Kegland Part Number: KL23443
It is really THAT easy to make good beer at home?+
YES! If you can follow a recipe and keep clean, there is nothing stopping you from making great beer in your home - beer you can be proud of and your friends will love! The MoreBeer! mission is to provide reliable equipment and quality ingredients that make the home brewing experience successful and satisfying. We'll get you started in home brewing the way we wish we had been started.
