Add a 1.5" TC flange to virtually any vessel! Weldless design Ideal for FTSs and Brew Bucket flat lid pressurized transfers Use with the Pressurized Transfer Fitting FE26 (as shown in pictures) 304 Stainless Construction High heat compatible silicone O-ring Requires TC Clamp and Gasket 42 mm carbide hole saw recommended for installation Please note this product only includes the three pieces displayed in the first photo.
PLEASE NOTE: The supplier of this product has temporarily halted shipments to addresses within the state of California. If you are a CA resident, please note your order will not be fulfilled and will ultimately be canceled. We hope to have this issue resolved with the supplier as soon as possible.
Large 11 gallon preboil capacity
Powerful 3,300 watt heating element
Color LCD controller magnetically mounted for easy removal and cleaning
Wireless control via the Grainfather Community App
Dual stage false bottom to prevent stuck sparges
Wort chiller included
The Grainfather G40 brewing system has a bigger capacity and better connectivity. Produce up to 40L (11 US Gal) of beer from one brew and connect your mobile device to the smart controller with built-in wireless control via the Grainfather App, for step-by-step brewing and access to bazillions of recipes.
The Grainfather G40 is the latest brewing system in the G Series range from Grainfather. Packed with all of the innovative features you can find in the G70, this brewing system is your new best friend for brews up to 11 gal (40L), perfect to fill two 5 gal corny kegs. With a max grain bill of 29 lb., you can choose to add extra grain and less liquid to make beer with an ABV over 9%.
Manage your brew remotely with step-by-step brewing with the smart wireless controller. All you need to do is connect your mobile device to the controller and control your brew through the FREE Grainfather app where you have access to bazillions of recipes to choose from, or create your own!
Please Note - this system comes standard with a NEMA 6-15P plug, and requires access to a 220v-240v power supply.
Features:
G40 body built with sleek 304-grade stainless steel
Large, surface mounted heated elements heat wort evenly
Connect your mobile device to the smart wireless controller via the Grainfather App (link to the Grainfather app page) and manage your brew remotely. The Grainfather app gives you access to brewing tools and calculators to brew with confidence, and bazillions of recipes to choose from or create your own.
Reach your expected gravity with a conical base for maximum wort transfer
Comes with a counterflow wort chiller for a more efficient and sanitary brew transfer
PID heating control for accurate temperature management during mashing
Quick and easy cleaning with CIP (clean in place) capability
An integrated sight glass for easy volume reading
Rolled edge mash plate and large hop filter to reduce blockages
What's Included:
Grainfather G40
Smart controller with built-in wireless connectivity
Counterflow wort chiller
Glass lid
Lifting bar
Inner basket
Recirculation hose
Grain plate
Hop filter
Fittings
Specs:
Size: 26" x 21"
Weight: 64lb
Capacity: 12 gal
Batch volume
Maximum: 11 gal (40L)
Minimum: 3 gal (10L)
Grain bill
Maximum: 29 lb (13kg)*
Minimum: 7 lb (3kg)
*Max weight depends on grain crush, type, and variety. Large grain bills may also require the use of an additional grain plate."
Power: 3300W, 240V
Connectivity: Wireless control
Premium Counter-Pressure Bottle filler that is designed for the smaller craft brewer or dedicated homebrewer to help make bottling day faster and more efficient
The four separate filling heads have individual Stainless Steel 3-way control valves that allow for quick fill rates
Only requires one person to operate
A single PRV provides equal backpressure on all heads resulting in matching flow rates without adjustment
Individual purge valves on each fill head allow for nearly all oxygen removal in a bottle, ensuring that the beer stays fresh for longer
The removable drip tray is fully draining with a barbed outlet for constant filling and easy cleaning
A purge valve on the reservoir helps make sure that foam never builds up
304 Stainless Steel Construction and easy-to-use functionality, all resulting in a top-of-the-line bottle filler
Introducing the newly redesigned and updated G2 Medusa Multihead Counter Pressure Bottle Filler! This unique unit was designed in-house by the MB Pro Engineering team and purpose built for the smaller craft brewer or dedicated homebrewer. The Medusa will speed up bottling day while also reducing exposure to oxygen during the bottling process, resulting in higher quality beer with a longer shelf life.
The Medusa Multihead Counter Pressure Bottle Filler can be adjusted to cater all bottling needs. All four heads can be operated individually, and the height, back pressure, and fill speeds can be adjusted for various bottle styles. We've done our best to pack this unit with features that will handle all jobs, while keeping costs as low as possible.
Features:
3-way stainless steel valves on both inlet & back pressure sides of all fill heads.
Improved Pressure Relief Valve has higher accuracy over fill rates, and directs foam into the drip tray rather than onto your bottles.
Robust stainless steel frame stands on its own or can be easily bolted or clamped to a work surface
Stainless steel fill reservoir keeps fill rates equal & reduces foaming
Inverted fill tubes & reservoir purge means cleaner filling with even less possibility for foam.
Dual TC Fill reservoir is easier to clean & allows for upgrades down the road (as they become available).
Easily adaptable to fill from nearly any pressurized vessel.
Height is adjustable from shorty bottles to growlers.
Easy disassembly for cleaning, storage & maintenance,
Sanitary 1.5" TC inlet for beer (Clamp and Gasket sold separately)
3/8" tube connection for CO2.
Backpressure Bar allows for a single adjustment point for fill rates. No more adjusting PRVs on each fill head.
Minimum Bottle Height: 6.9"
Maximum Bottle Height: 16.5"
Maximum Working Pressure: 15 PSI
Dimensions:
Footprint: 26-3/8" L x 8" W
Drip Tray: 23-1/2" L x 5-1/2" W
Overall Height: 25-3/8"
Please Note: Filler valves include a Teflon gasket. Do not soak the valves in PBW which can corrode Teflon material after prolonged contact.
